Rix Optics DBH-D12 1280×1024 Thermal Scope, 75mm LRF

The Rix Optics DBH-D12 is a thermal imaging scope built around a 1280x1024 uncooled VOx sensor and 75mm F1.0 objective lens. It features a 905nm laser rangefinder, 2560x2560 OLED display, Wi-Fi integration, and onboard photo and video recording for practical field observation and documentation.

Designed for use on rifled weapons, the DBH-D12 combines thermal imaging with a stepped digital zoom, picture-in-picture viewing, and a stated maximum recoil rating of 1000g/6000 joules.

Key Specifications

• The thermal sensor provides 1280×1024 resolution with a 12-micron pixel pitch.
• The sensor uses an uncooled VOx design with a 50Hz frame rate.
• The objective lens is a 75mm F1.0 optic.
• The optical system provides 3x optical zoom.
• The digital zoom operates from 3x to 20x in stepped increments.
• The field of view is listed as 11.7° × 9.3° at 100 yards.
• The OLED display provides 2560×2560 resolution.
• The laser rangefinder uses a 905nm wavelength and has a stated maximum range of 1312 yards.
• The optic includes Wi-Fi connectivity and a built-in video recorder for photo and video capture.
• The housing is rated IP67 waterproof and includes stated resistance to 1000g/6000 joules of recoil force.

With its high-resolution thermal sensor, large-aperture objective, integrated rangefinder, and durable IP67-rated housing, the DBH-D12 provides a feature-rich thermal optic platform for demanding observation and shooting applications.
